GYTC8A

Single-mode optical fiber cable
Indoor SM optical fiber cable
Multi-mode optical fiber cable
Indoor MM optical fiber cable
Outdoor optical fiber cable

Send Inquiry

Product Introduction

Single-mode optical fiber cable

Indoor SM optical fiber cable

Multi-mode optical fiber cable

Indoor MM optical fiber cable

Outdoor optical fiber cable

Fiber core 2 core / 4 core / 6 core / 8 core / 12 core / 24 / 36 / 48 / 72 / 96 / 144 / 216 / 288 core

Characteristics

1. Excellent mechanical and temperature performance.

2. Special tube filling compound ensure a critical protection of fibre and resist the water.

3. Loose tube stranding cable core ensures the cable structure stable.

4. Loose tube completely filling compound to ensure the cable watertight.

5. High tensile strength of stranded wires meet the requirement of self-supporting and reduce the installation.

6. Outer sheath protects cable from ultraviolet radiation.

7. Optional Aluminum or corrugated steel sheathing.

Standards

GYTC8A cable complies with Standard YD/T 1155-2001 as well as IEC 60794-1.

Optical Characteristics

		G.652	G.655	50/125μm	62.5/125μm
Attenuation (+20℃)	@850nm			≤3.0 dB/km	≤3.0 dB/km
	@1300nm			≤1.0 dB/km	≤1.0 dB/km
	@1310nm	≤0.36 dB/km	≤0.40 dB/km
	@1550nm	≤0.22 dB/km	≤0.23dB/km
Bandwidth (Class A)	@850nm			≥500 MHz·km	≥200 MHz·km
Bandwidth (Class A)	@1300nm			≥1000 MHz·km	≥600 MHz·km
Numerical Aperture				0.200±0.015NA	0.275±0.015NA
Cable Cut-off Wavelength		≤1260nm	≤1480nm

Technical Parameters

Cable Type	Fiber Count	Tubes	Fillers	Cable Diameter mm	Cable Weight kg/km	Tensile Strength Long/Short Term N	Crush Resistance Long/Short Term N/100mm	Bending Radius Static/Dynamic mm
GYTC8A-2~6	2~6	1	4	9.5×18.3	218	600/1500	300/1000	10D/20D
GYTC8A-8~12	8~12	2	3	9.5×18.3	218	600/1500	300/1000	10D/20D
GYTC8A-14~18	14~18	3	2	9.5×18.3	218	600/1500	300/1000	10D/20D
GYTC8A -20~24	20~24	4	1	9.5×18.3	218	600/1500	300/1000	10D/20D
GYTC8A-26~30	26~30	5	0	9.5×18.3	218	600/1500	300/1000	10D/20D

Storage/Operating Temperature: -40℃ to + 70℃
