GYXTW Outdoor Optical Cable
GYXTW 2-24 Core Outdoor Optical Fiber Cable
Product Structure Diagram
Product Description
GYXTW outdoor fiber optic cable, is also called single loose tube steel tape armored cable, is consisted of 250um fibers held in an gel filled central loose tube surrounded by water-blocking tape an den cased in corrugated, polyethylene laminated steel tape. The cable features two parallel steel wire strength members encased in the PE outer jacket.
Application
Adapted to outdoor distribution. - Suitable for external applications in ducts and aerial applications. - Long distance and local area network communication
Technical Specifications
|
Cable Count (Core) |
Out Sheath Diameter （MM) |
Weight （KG) |
Minimum Allowable Tensile Strength(N) |
Minimum Allowable Crush Load （N/100mm) |
Min Bending Radius (MM) |
Suitable Temperature （℃） |
|||
|
Short -term |
Long -term |
Short -term |
Long -term |
Short -term |
Long -term |
||||
|
2 |
8.3 |
78.00 |
1500 |
600 |
1000 |
300 |
20D |
10D |
-40 to +60 |
|
4 |
8.3 |
78.00 |
1500 |
600 |
1000 |
300 |
20D |
10D |
|
|
6 |
8.3 |
78.00 |
1500 |
600 |
1000 |
300 |
20D |
10D |
|
|
8 |
8.3 |
78.00 |
1500 |
600 |
1000 |
300 |
20D |
10D |
|
|
12 |
8.3 |
78.00 |
1500 |
600 |
1000 |
300 |
20D |
10D |
|
|
24 |
8.3 |
78.00 |
1500 |
600 |
1000 |
300 |
20D |
10D |
|
