Blockless Splitter

FDB series are applicable in FTTH project and suitable for outdoor application. They can distribute cables with a splitter. They have the subsequent functions of mechanical splice, fusion splice, distributions, etc.

Send Inquiry

Product Introduction

Features

Telcordia GR-1209-CORE-2001

Telcordia GR-1221-CORE-1999

YD/T 2000.1-2009

RoHS

Product Details

1X N (N≥2)

PARAMETERS		1×2	1×4	1×8	1×16	1×32	1×64	1×128
Wavelength (nm)		1260～1650
Fiber type		G657A 1or custom-defined
Pigtail length (m)		1.0 (±0.1) or custom-defined
Insertion loss (dB)		≤3.8	≤7.2	≤10.3	≤13.6	≤16.9	≤20.4	≤23.5
Loss uniformity (dB)	max	≤0.8	≤1.0	≤1.2	≤1.5	≤1.8	≤2.0	≤2.0
Return loss (dB)	minimum	55	55	55	55	55	55	55
PDL (dB)	max	≤0.2	≤0.2	≤0.3	≤0.3	≤0.4	≤0.4	≤0.4
Directivity	minimum	≥55
Wavelength related loss (dB)	max	≤0.6	≤0.6	≤0.6	≤0.8	≤1.0	≤1.0	≤1.2
Working temp. (℃)	-40～85
Store temp. (℃)	-40～85
Bare fiber		40×4×4			50×7×4		60×12×4	1202610
ABS package size (LxWxH)mm		100×80×10			120×80×18		140×115×18	15013025
Mini package size (Lx W x H)mm		55×7×4			60×12×4	80×20×6	100×40×6	1205012

2X N (N≥2)

PARAMETERS		2×2	2×4	2×8	2×16	2×32	2×64	2×128
Wavelength (nm)		1260～1650
Fiber type		G657A 2 or custom-defined
Pigtail length (m)		1.0 (±0.1) or custom-defined
Insertion loss (dB)		≤4.2	≤7.5	≤10.6	≤13.9	≤17.2	≤20.8	≤23.8
Loss uniformity (dB)	max	≤0.8	≤1.0	≤1.2	≤1.5	≤1.8	≤2.0	≤2.0
Return loss (dB)	minimum	55	55	55	55	55	55	55
PDL (dB)	max	≤0.2	≤0.2	≤0.3	≤0.3	≤0.4	≤0.4	≤0.4
Directivity	minimum	≥55
Wavelength related loss (dB)	max	≤0.6	≤0.6	≤0.6	≤0.8	≤1.0	≤1.0	≤1.2
Working temp. (℃)	-40～85
Store temp. (℃)	-40～85
Bare fiber		50×4×4			50×7×4		60×12×4	1202610
ABS package size (LxWxH)mm		100×80×10			120×80×18		140×115×18	15013025
Mini package size (LxWxH)mm		60×7×4			60×12×4	80×20×6	100×40×6	1205012

Remark: these datas not include connector loss,Each connector will add 0.25dB loss, each adapter will add extra 0.2dB loss

Application

● FTTH (Fiber to the home)

● Access/PON distribution

● CATV NETWORK

● High reliability/Monitoring/other Network systems

1x(2,4...128) or 2x(2,4...128) PLC Splitter in FTTH Solution

The standard LGX box PLC splitter /Insert type PLC splitter provides a plug-and-play method for integration in the network, which eliminates any risks during installation. It eliminates the need for splicing machines on the field and there is no need for skilled personnel for deployment. The following figure shows 1x4 LGX PLC Splitter applied in the 1U rack chassis in GPON network.
