Figure 8 Armored Optical Cable GYFC8A-12B1.3

8字型铠装光缆 Figure 8 Armored optical cable（Self-supporting）

GYFC8A-12B1.3

光缆结构图Structure Diagram





光纤参数 Fiber Parameters

编号No.	项目Items			单位Unit	参数Specification
					G.652D
1	模场直径Mode Field Diameter	1310nm		μm	9.2±0.4
2	包层直径Cladding Diameter			μm	125.0±1
3	包层不圆度Cladding Non-Circularity			%	≤1.0
4	芯/包层同心度误差 Core-Cladding Concentricity Error			μm	≤0.6
5	涂覆层直径Coating Diameter			μm	245±10
6	涂覆层不圆度Coating Non-Circularity			%	≤6.0
7	包层/涂覆层同心度误差 Cladding-Coating Concentricity Error			μm	<12.5
8	光缆截止波长Cable Cutoff Wavelength			nm	λcc≤1260
9	衰减系数 Attenuation(max.)		1310nm	dB/km	≤0.35
			1550nm	dB/km	≤0.22



3.光缆参数 Cable Parameters

项目Items		指标Specifications
		GYFC8A-24
中心加强件 Central Strength Member	外径Diameter	3.8mm
	材料Material	2.5mmFRP
着色涂覆光纤 Colored Coating Fiber	光纤颜色Fiber color	蓝Blue、橙Orange、绿Green、棕Brown灰Gray、白White、红Red、黑Black、黄yellow、紫Violet、粉红Pink、青绿Aqua
松套管 Loose Tube	外径Diameter	1.2mm
	材料Material	PBT
	层套管数 Number of tube	12
	色序 Color sequence	一管一芯色序One tube one core color
	色序 Color sequence	蓝 Blue/橙Orange/绿Green/棕Brown/灰Gray/白White/红Red /黑Black/黄yellow/紫Violet/粉红Pink /青绿Aqua
填充纱 Filling yarn	数量 Number	5
撕裂绳 Rip cord	数量 Number	2
	颜色 Color	黄Yellow
铝带Al wrap tape	厚度Thickness	0.2mm
吊线 Messenger Wire	规格Diameter	1.2mm*7
	线经Wire Diameter	3.6mm
	厚度Thickness	1.2mm
外护层 Outer Jacket	材料Material	PE
	厚度Thickness	1.6mm
	颜色Color	黑 Black
	凹槽Notch	平行凹槽Parallel notch
光缆外径Cable diameter	11.2±0.5mm x 18.2±0.5mm
光缆重量Cable weight (kg/km)	(180±15)kg/km



4. 光缆机械和环境性能 Mechanical and Environmental Characteristics

项目 Items	指标 Specifications	试验方法 Test Standard
拉伸性能 Tensile performance	2850N	IEC 60794-1-2 E1
压扁性能 Cable crush	2200N/100mm	IEC 60794-1-2 E3
冲击 Lmpact	6.5J,H/0.3m, 5points 3 cycle	IEC 60794-1-2 E4
反复弯曲Repeated bending	40D，50cycle	IEC 60794-1-2 E6
扭转Torsion	2m, ±90° 300cycle，	IEC 60794-1-2 E7
渗水性能 Water penetration	3m length, 1m/24hrs	IEC 60794-1-2 F5B
安装温度 Installation Temperature	-10～+50℃
工作温度 Operating Temperature	-20～+70℃
储存温度 Storage Temperature	-20～+70℃
